Originally posted at blog.milhamh.dev Prerequisite GitLab account macOS If you want to. Tagged with git, gitlab, macos. The OpenSSH server reads a configuration file when it is started. Usually this file is /etc/ssh/sshdconfig, but the location can be changed using the -f command line option when starting sshd. Some organizations run multiple SSH servers at different port numbers, specifying a different configuration file for each server using this option. SSH Config Editor is a handy tool for manage your OpenSSH ssh client configuration file. You can add or edit identity files, port forwardings (with handy.

If you're anything like me, you probably log in and out of a half dozen remote servers (or these days, local virtual machines) on a daily basis. And if you're even more like me, you have trouble remembering all of the various usernames, remote addresses and command line options for things like specifying a non-standard connection port or forwarding local ports to the remote machine.

Shell Aliases


Let's say that you have a remote server named dev.example.com, which has not been set up with public/private keys for password-less logins. The username to the remote account is fooey, and to reduce the number of scripted login attempts, you've decided to change the default SSH port to 2200 from the normal default of 22. This means that a typical command would look like:


$ ssh [email protected] -p 22000

password: *************


Not too bad.


We can make things simpler and more secure by using a public/private key pair; I highly recommend using ssh-copy-id for moving your public keys around. It will save you quite a few folder/file permission headaches.


$ ssh [email protected] -p 22000

# Assuming your keys are properly setup…


Now this doesn't seem all that bad. To cut down on the verbosity you could create a simple alias in your shell as well:


$ alias dev='ssh [email protected] -p 22000'

$ dev # To connect


This works surprisingly well: Every new server you need to connect to, just add an alias to your .bashrc (or .zshrc if you hang with the cool kids), and voilĂ .

~/.ssh/config


Ssh

However, there's a much more elegant and flexible solution to this problem. Enter the SSH config file:


# contents of $HOME/.ssh/config

Host dev

HostName dev.example.com

Port 22000

User fooey


This means that I can simply $ ssh dev, and the options will be read from the configuration file. Easy peasy. Let's see what else we can do with just a few simple configuration directives.


Personally, I use quite a few public/private keypairs for the various servers and services that I use, to ensure that in the event of having one of my keys compromised the damage is as restricted as possible. For example, I have a key that I use uniquely for my Github account. Let's set it up so that that particular private key is used for all my github-related operations:


Host dev

HostName dev.example.com

Port 22000

User fooey

Host github.com

Ssh Config File Windows 10

IdentityFile ~/.ssh/github.key


The use of IdentityFile allows me to specify exactly which private key I wish to use for authentification with the given host. You can, of course, simply specify this as a command line option for 'normal' connections:

Openssh Config File Examples


$ ssh -i ~/.ssh/blah.key [email protected]


but the use of a config file with IdentityFile is pretty much your only option if you want to specify which identity to use for any git commands. This also opens up the very interesting concept of further segmenting your github keys on something like a per-project or per-organization basis:


Host github-project1

User git

HostName github.com

IdentityFile ~/.ssh/github.project1.key

Host github-org

User git

HostName github.com

IdentityFile ~/.ssh/github.org.key

Host github.com

User git

IdentityFile ~/.ssh/github.key


ExamplesOpen

Which means that if I want to clone a repository using my organization credentials, I would use the following:


$ git clone [email protected]:orgname/some_repository.git


Going further


As any security-conscious developer would do, I set up firewalls on all of my servers and make them as restrictive as possible; in many cases, this means that the only ports that I leave open are 80/443 (for webservers), and port 22 for SSH (or whatever I might have remapped it to for obfuscation purposes). On the surface, this seems to prevent me from using things like a desktop MySQL GUI client, which expect port 3306 to be open and accessible on the remote server in question. The informed reader will note, however, that a simple local port forward can save you:


$ ssh -f -N -L 9906:127.0.0.1:3306 [email protected]

# -f puts ssh in background

# -N makes it not execute a remote command


This will forward all local port 9906 traffic to port 3306 on the remote database.example.com server, letting me point my desktop GUI to localhost (127.0.0.1:9906) and have it behave exactly as if I had exposed port 3306 on the remote server and connected directly to it.

Open Ssh Config File


Now I don't know about you, but remembering that sequence of flags and options for SSH can be a complete pain. Luckily, our config file can help alleviate that:


Host tunnel

HostName database.example.com

IdentityFile ~/.ssh/coolio.example.key

LocalForward 9906 127.0.0.1:3306

User coolio


Which means I can simply do:


$ ssh -f -N tunnel


Ssh Config Files

And my local port forwarding will be enabled using all of the configuration directives I set up for the tunnel host. Slick.

Homework


There are quite a few configuration options that you can specify in ~/.ssh/config, and I highly suggest consulting the online documentation or the ssh_config man page. Some interesting/useful things that you can do include: change the default number of connection attempts, specify local environment variables to be passed to the remote server upon connection, and even the use of * and ? wildcards for matching hosts.

Ssh Config File Format


Openssh Config File Windows

I hope that some of this is useful to a few of you. Leave a note in the comments if you have any cool tricks for the SSH config file; I'm always on the lookout for fun hacks.
